Replace or Add Solar Pool Panels

Replacing leaking panels, expanding your existing system, or replacing an entire panel array? Get help choosing Techno-Solis panels and the hardware needed for your project.

Already know what you need? Shop 1.5" & 2" Header Solar Pool Panels

Commercial-Grade Compatible Solar Pool Panels

What Are You Planning?


Replace leaking or damaged panels. Check your existing brand and model before choosing a replacement.


Expand your existing array. Get help checking panel compatibility, available space, and system layout.


Replace all existing collectors with a Standard Kit containing panels, connecting and mounting hardware.

USE TECHNO-SOLIS SOLAR POOL PANELS TO REPLACE YOUR DEFECTIVE PANELS

Check Your Panel Connections

Check Your Panel Connections

Look at the joint between two panels before choosing a replacement.

Solar thermal panel coupling adjustment.png

Techno-Solis panels use rubber couplings secured with hose clamps. If your panels connect this way, the next step is to check header size, panel dimensions, and compatibility with your existing system.

Aligned solar heating panel joints.png

Techno-Solis panels are not direct individual replacements for panels using other connection types. If you’re replacing the complete panel array, a Standard Kit may be an option.

Not Sure Which Connection You Have?

Send us a clear close-up photo of the connection between your panels.

Matching connections does not confirm compatibility. Panel construction, flow, drainage, and dimensions also matter.

Check Your Header Size

Most rubber coupling solar pool panels have either 1.5-inch and 2-inch nominal headers.


1.5"
Nominal Headers

Techno-Solis_2_inch_header (2).png

2"
Nominal Headers

Six measurements tell us the whole story

By measuring the header inside diameter, header outside diameter, absorber width, overall panel width, overall panel length, and header-to-header length, you can accurately compare your existing solar pool panel to the closest Techno-Solis replacement option. These measurements will help you confirm the fit before you order.

​01

Header inside diameter | I.D.
Measure straight across the inside opening of the round header.

02

Header outside diameter | O.D.
Measure straight across the widest outside edge of the round header.

03

Absorber width
Measure the width of the active solar absorber area between the outside edges of the panel body.

04

Overall panel width
Measure the full width of the panel from the outermost edge of one header end to the other.

05

Overall panel length
Measure the complete length of the collector from the top outside edge to the bottom outside edge.

06

Header-to-header length
Measure the distance between the inside edges of the top and bottom headers.


Techno-Solis Panel Sizes & Features

Manufactured in Florida, Techno-Solis solar pool heating panels are available with 1.5-inch or 2-inch nominal headers in three sizes: 4′ × 8′, 4′ × 10′, and 4′ × 12′.

Durable polymer construction designed to withstand sunlight, heat, and pool environments.

Select Your Header Size

Choose your confirmed header size below to browse available panels and connecting hardware options.

Choose from 4′ × 8′, 4′ × 10′, or 4′ × 12′ panels with 1.5-inch headers, available as panel only or with connecting hardware.

TECHNO-SOLIS 1.5" Header Solar Pool Panels

Choose from 4′ × 8′, 4′ × 10′, or 4′ × 12′ panels with 2-inch headers, available as panel only or with connecting hardware.

TECHNO-SOLIS 2" Header Solar Pool Panels​
